Product Summary

Introducing the Residential PV Battery Integration Kit (Model: RPIK-5.12L), a compact yet powerful 5.12kWh wall-mounted battery system engineered specifically for seamless integration with residential photovoltaic (PV) arrays. This kit serves as the cornerstone of a modern home energy ecosystem, enabling solar self-consumption, backup power, and time-of-use arbitrage. As a Tier-1 manufacturer, we offer a 10-Year Performance Warranty and local O&M support globally, ensuring your project’s long-term viability. This is not just a battery; it is a complete integration kit, including BMS, cabinet, and connectivity hardware, streamlining your installation process.

Why Choose This System

For commercial distributors and project integrators, the Residential PV Battery Integration Kit represents a superior sourcing opportunity. Its high cycle life (6,000+ cycles at 90% DoD) and smart liquid cooling system guarantee minimal degradation over its operational lifetime, maximizing ROI for your end-users. Our turnkey PV-Storage-Charging solutions are designed to be universally compatible, making this kit the ideal choice for residential and light commercial installations. We provide dedicated local O&M support and robust global shipping availability, ensuring you can deploy projects anywhere with confidence.

Key Advantages for Distributors:

• Low LCOE: Superior performance per dollar ensures high customer acquisition.
• Quick Commissioning: Plug-and-play design reduces on-site labor costs.
• Scalable: Supports parallel expansion up to 10 units for larger capacity needs.
• Safety Certified: Compliance with UL 9540 and IEC 62619 standards.

Product Overview & Safety Architecture

The RPIK-5.12L is more than an energy storage device; it’s a sophisticated safety and management asset. At its core lies a smart Battery Management System (BMS) that provides multi-layer protection against over-voltage, over-current, and temperature anomalies. The integrated active cell equalization technology ensures all cells operate uniformly, extending pack life and preventing capacity degradation. Housing the Tier-1 LFP cells is an IP65-rated, fire-retardant enclosure designed to withstand harsh environmental conditions, featuring an advanced multi-stage fire suppression system that sets a new industry standard for residential safety.

Safety & Protection Features:

• Cell-Level Protection: Individual cell voltage and temperature monitoring.
• Module-Level Protection: Isolation and short-circuit protection.
• System-Level Protection: Ground fault detection and arc fault circuit interruption.

Technical Specifications

Our engineers have refined every aspect of the RPIK-5.12L to ensure peak performance under diverse residential loads. The system leverages smart liquid cooling to maintain optimal thermal conditions, guaranteeing a consistent 90% round-trip efficiency. The table below outlines the precise technical parameters, highlighting the rigorous quality and capacity that define our brand.

Technical Feature	Specification
Battery Chemistry	Tier-1 LFP (LiFePO4)
Rated Capacity	5.12 kWh
Nominal Voltage	51.2 V DC
Operating Voltage Range	44.8 – 57.6 V DC
Max Charge / Discharge Current	100 A / 100 A
Cooling / Thermal Control	Smart Liquid Cooling (Active)
Cycle Life	≥6,000 cycles @ 25°C, 90% DoD
Round-Trip Efficiency	≥90.0%
IP Rating	IP65
Communication Protocols	CAN 2.0B, RS485, Wi-Fi (Optional)
Installation	Wall-Mounted
Operation Temperature	-20°C to +55°C
Storage Temperature	-10°C to +35°C
Weight	65 kg
Dimensions (W x H x D)	550 x 650 x 350 mm
Certifications	UL 9540, IEC 62619, CE, UN38.3

Key Performance Indicators:

• Rated Power: 3.0 kW / 5.0 kW
• Nominal Voltage: 51.2 V DC
• Usable Energy: 5.12 kWh (Configurable)
• Max. Efficiency: 98.0%
• Depth of Discharge (DoD): 90%
• Cycle Life: ≥6,000 cycles @ 25°C, 90% DoD
• Communication Protocol: CAN 2.0B, RS485, Wi-Fi/4G
• Dimension (W×D×H): 550×350×650 mm
• Weight: 65 kg

Application Scenarios

EV Supercharging Stations

The Residential PV Battery Integration Kit is a perfect fit for small to medium EV charging stations, particularly in commercial complexes and community hubs. By integrating with solar carports, this system can store solar energy during off-peak hours and deliver high-power output to charging piles during peak demand, significantly reducing energy costs and alleviating grid stress. This creates a sustainable, self-sufficient micro-grid that drives EV adoption.

Residential & Micro-Grid Projects

Tailored for modern smart homes, the kit enables complete energy independence. It seamlessly switches between on-grid and off-grid modes, ensuring uninterrupted power supply during outages. Its plug-and-play nature and flexible expansion options make it suitable for small factories, agricultural facilities, and remote communication stations.

Supply Assurance

As a specialized manufacturer, we have a robust supply chain and a production capacity exceeding 1 GWh per year. We guarantee ready-to-deploy inventory with lead times as low as 15 days for bulk orders. Our global sea shipping network is optimized for efficiency and cost, ensuring your cargo arrives safely and on time. We provide comprehensive after-sales support, including local O&M services in over 50 countries, ensuring your projects deliver peak performance throughout their lifecycle.

Frequently Asked Questions

What is the typical lead time for a wholesale order of the Residential PV Battery Integration Kit?

For standard orders, the lead time is 15-20 working days after order confirmation and deposit. Our robust inventory of core components allows us to expedite delivery for urgent projects.

Can this system operate independently (off-grid) during a power outage?

Yes, the Residential PV Battery Integration Kit features a seamless transition mode. It can switch to an off-grid backup mode within milliseconds, providing immediate backup power to critical loads. For full off-grid capacity, please ensure your inverter configuration is compatible.

How does the 10-Year Performance Warranty work, and what does it cover?

Our 10-Year Performance Warranty guarantees that the system will maintain at least 70% of its initial usable capacity. It covers all major components, including the LFP battery cells and BMS. Our dedicated global service team is available for full support, including part replacement and remote diagnostics.

Is this kit compatible with my existing PV inverter and solar panels?

It is designed for broad compatibility with most hybrid and battery-ready PV inverters. We recommend reviewing the communication protocols (CAN/RS485) and voltage parameters listed in the specifications table. For specific compatibility questions, our technical pre-sales team can provide detailed integration guidance and checklists.

What are the storage and operating temperature requirements?

The RPIK-5.12L is engineered to operate efficiently within a broad temperature range of -20°C to +55°C. The built-in liquid cooling system ensures stable performance, even under high ambient temperatures, while the advanced BMS actively manages thermal runaway risks. For long-term storage, we recommend a cool, dry environment between -10°C and +35°C.
