Ready to Deploy: Terminal Block Commercial Battery ESS | 10-Year Warranty & Local O&M

Product Summary

Introducing the Terminal Block, a next-generation commercial and industrial (C&I) energy storage system engineered for maximum return on investment. This ready-to-deploy BESS unit integrates Tier-1 LFP battery cells with an advanced smart liquid cooling system, delivering a usable capacity of 233kWh to 1.5MWh per cabinet. Built to support the most demanding applications—from EV supercharging stations to micro-grids—the Terminal Block offers a 10-year performance warranty, global shipping availability, and a low total cost of ownership (LCOE) that outperforms diesel alternatives.

Why C&I Sourcing Chooses Terminal Block (High ROI)

For project developers and facility managers, the Terminal Block represents a direct path to energy independence and peak shaving profits. Our system achieves a 94% round-trip efficiency with a designed life of over 8,000 cycles at 90% Depth of Discharge (DoD). This chemistry ensures minimal capacity degradation, maximizing your arbitrage revenue. As a global supplier, we provide turnkey PV-storage-charging solutions and local O&M support, ensuring your project’s operational cash flow is protected from day one.

Product Overview & Safety Architecture

The Terminal Block cabinet features a compact, modular design that minimizes footprint while maximizing power density. The core safety architecture includes a 4-level Battery Management System (BMS) with active cell balancing, an integrated aerosol fire suppression system, and IP55-rated outdoor housing. The smart liquid cooling loop maintains optimal cell temperature variance within ±2°C, significantly reducing thermal runaway risks and boosting overall cycle life. Advanced EMS (Energy Management System) allows for seamless integration with existing solar canopies and grid connections, enabling both on-grid and off-grid operations.

Technical Specifications

Base Model Parameters (Terminal Block-233):
Battery Chemistry: Tier-1 LFP (LiFePO4)
Usable Energy: 233 kWh
System Voltage: 768 Vdc
Cooling System: Smart Liquid Cooling (Inlet/Outlet Temp Control)
Round-trip Efficiency: ≥94%
Cycle Life: 8,000 cycles @ 25°C, 90% DoD (End of Life 70% SOH)
Dimensions (WxDxH): 1300 x 1500 x 2300 mm
Weight: 2,400 kg
Communication Protocols: CAN, Modbus TCP/IP, IEC 61850
Certifications: UL 9540A, IEC 62619, CE, UN38.3
Protection Class: IP55 (Outdoor rated), C3 anti-corrosion
Parallel Scalability: Up to 10 units (2.33 MWh) via busbar linkage

Technical Feature	Specification
Battery Chemistry	Tier-1 LFP (LiFePO4)
Cooling / Thermal Control	Smart Liquid Cooling (±2°C variance)
Usable Energy per Rack	233 kWh (expandable to 1.5MWh)
Cycle Life (25°C)	8,000 cycles @ 90% DoD
Warranty	10 Years / Unlimited Cycles
Safety Certified	UL 9540A, IEC 62619, CE

Application Scenarios

EV Supercharging Stations (Turnkey PV-Storage-Charging)

The Terminal Block is the ideal buffer for ultra-fast EV chargers. By storing low-cost off-peak energy or on-site solar generation, it slashes demand charges and enables grid-friendly high-power charging. Our Local O&M teams provide rapid commissioning and lifecycle support, ensuring uptime for public charging infrastructure.

Industrial Parks & Peak Shaving

Manufacturing facilities can deploy the Terminal Block to reduce peak demand penalties. The system’s EMS actively dispatches stored energy during high-tariff periods, delivering immediate ROI and stabilizing production line power quality. With global sea shipping availability and 10-year direct quality assurance, large-scale rollouts are simple and secure.

Supply Assurance & Global Delivery

As an upstream manufacturer, we control the entire supply chain—from cell sourcing to final assembly. This allows for 2-4 week lead times for standard Terminal Block units, with ODM/OEM customization available for turnkey projects. Every unit undergoes a strict Factory Acceptance Test (FAT) before palletized sea shipping. We offer door-to-door logistics support including customs clearance, making international procurement effortless.

Frequently Asked Questions (B2B Procurement)

What is the typical shipping time for a Terminal Block unit?

Standard lead time is 25-30 days after deposit confirmation. We offer fast-track shipping options for urgent projects through our global logistics network.

Does the 10-Year Warranty cover all components?

Yes, our 10-Year Performance Warranty covers the entire BESS, including LFP cells, BMS, and cooling system, provided standard O&M guidelines are followed. We guarantee 70% usable capacity retention at year 10.

Can the Terminal Block integrate with existing PV inverters?

Absolutely. The AC coupling architecture supports virtually all major inverter brands. Our technical team provides remote EMS configuration as part of the turnkey solution.

What local support options exist outside your home market?

We maintain a network of certified local O&M partners in North America, Europe, and SEA. This includes 24/7 remote monitoring, on-site repair SLAs, and spare parts warehousing.

How do I calculate the right capacity for my project?

Our pre-sales engineering team analyzes your load curve, peak demand charges, and solar generation to deliver a capacity sizing report and ROI model, free of charge.
